NCEP6090AK
VDS =60V,ID =90A RDS(ON) < 8.0mΩ @ VGS=10V (Typ:7.2mΩ) RDS(ON) < 9.5mΩ @ VGS=4.5V (Typ:8.6mΩ)
Excellent gate charge x RDS(on) product
Very low on-resistance RDS(on)
Pb-free lead plating
100% UIS tested
NCEP6090D
DC/DC Converter
Ideal for high-frequency switching and synchronous rectification
NCEP6090GU
VDS =60V,ID =90A RDS(ON)=2.9mΩ (typical) @ VGS=10V
Excellent gate charge x RDS(on) product(FOM)
Very low on-resistance RDS(on)
150 °C operating temperature
Pb-free lead plating
NCEP6090K
VDS=60V,ID=90A RDS(ON)< 6.9mΩ @ VGS=10V (Typ:6.4mΩ)
Excellent gate charge x RDS(on)product
Very low on-resistance RDS(on)
Pb-free lead plating
100% UIS tested
NCEP60T12A
VDS=60V,ID=120A RDS(ON)< 4.0mΩ @ VGS=10V (Typ:3.5mΩ) RDS(ON)< 5.0mΩ @ VGS=4.5V (Typ:4.0mΩ)
Excellent gate charge x RDS(on) product
Very low on-resistance RDS(on)
175 °C operating temperature
Pb-free lead plating
100% UIS tested
NCEP60T12AD
DC/DC Converter
Ideal for high-frequency switching and synchronous rectification
NCEP60T12AK
VDS =60V,ID =120A RDS(ON) < 4.0mΩ @ VGS=10V (Typ:3.5mΩ) RDS(ON) < 5.0mΩ @ VGS=4.5V (Typ:4.0mΩ)
Excellent gate charge x RDS(on) product
Very low on-resistance RDS(on)
175 °C operating temperature
Pb-free lead plating
100% UIS tested
NCEP60T12K
VDS =60V,ID =120A RDS(ON) < 4.0mΩ @ VGS=10V (Typ:3.6mΩ)
Excellent gate charge x RDS(on) product
Very low on-resistance RDS(on)
175 °C operating temperature
Pb-free lead plating
100% UIS tested
NCEP60T12T
VDS =60V,ID =120A RDS(ON) < 4.0mΩ @ VGS=10V (Typ:3.5mΩ)
Excellent gate charge x RDS(on) product
Very low on-resistance RDS(on)
175 °C operating temperature
Pb-free lead plating
100% UIS tested
NCEP60T15AG
VDS =60V,ID =150A RDS(ON) < 3.0mΩ @ VGS=10V (Typ:2.7mΩ) RDS(ON) < 3.3mΩ @ VGS=4.5V (Typ:2.9mΩ)
Excellent gate charge x RDS(on) product
Very low on-resistance RDS(on)
150 °C operating temperature
Pb-free lead plating
100% UIS tested
NCEP60T15G
VDS=60V,ID=150A RDS(ON)< 3.3mΩ @ VGS=10V (Typ:2.8mΩ)
Excellent gate charge x RDS(on)product
150 °C operating temperature
Pb-free lead plating
100% UIS tested
NCEP60T18
VDS=60V,ID=180A RDS(ON)< 3.2mΩ @ VGS=10V (Typ:2.8mΩ)
Excellent gate charge x RDS(on) product
Very low on-resistance RDS(on)
175 °C operating temperature
Pb-free lead plating
100% UIS tested
NCEP60T18A
VDS =60V,ID =180A RDS(ON) < 2.9mΩ @ VGS=10V (Typ:2.5mΩ) RDS(ON) < 3.4mΩ @ VGS=4.5V (Typ:3.0mΩ)
Excellent gate charge x RDS(on) product
Very low on-resistance RDS(on)
150 °C operating temperature
Pb-free lead plating
100% UIS tested
NCEP60T18D
VDS =60V,ID =180A RDS(ON) < 3.2mΩ @ VGS=10V (Typ:2.8mΩ)
Excellent gate charge x RDS(on) product
Very low on-resistance RDS(on)
150 °C operating temperature
Pb-free lead plating
100% UIS tested
NCEP60T20
VDS=60V,ID=200A RDS(ON)=1.8mΩ (typical) @ VGS=10V
Excellent gate charge x RDS(on) product
Very low on-resistance RDS(on)
175 °C operating temperature
Pb-free lead plating
100% UIS tested
